| MILspec：MIL-C-83513 | Housing material; aluminum alloy/stainless steel |
| Gender:Plug | Contact material: copper alloy |
| Mating Cycles:500 | Operating current: 3A |
| Connector type: miniature electrical connector | Voltage rating: 500V |
| Highlights:MIL-C-83513 Micro Electrical Connector | |
| Highlights: RectangularMIL-C-83513 Micro Electrical Connector | |
| Highlight: Female rectangularMIL-C-83513 | |
| Packaging Details: Standard Export Packaging | Delivery time:1-4 weeks |
| Payment method: | Supply capacity: 100,000 |
Connector Solution Rectangular connector accordingto MIL-DTL-83513J30J-9TJSLPlug Part Number:J30J-9TJSL
Description:MIL-DTL-83513 MiniatureD-connector is a female receptacle for electrical interconnection applications, meeting the stringent requirements of military and aerospace environments, it is a reliable connector, gold plated nickel plated contacts, 500V voltage rating, 500 mating cycles, part number:J30J-9TJSL
This connector is designed for superior performance in a wide range of applications including computer systems, data acquisition systems, communication systems, control systems navigation systems and instrumentation systems. It is a lightweight, cost-effective, easy-to-use solution with excellent electrical and mechanical properties. The connector has a robust construction, high vibration and shock resistance, and can withstand extreme temperatures, humidity, and harsh environments at high altitudes.
The MIL-C-83513connector offers excellent reliability and durability performance, making it the ideal solution for reliability applications. It is also ROHS compliant and certified to meet stringent quality standards, which means that the connector is designed to provide reliable and secure connections for a wide range of applications.
Product Name: MIL-C-83513Connector
Product Specification: MIL-C-83513
Part Number: J30J-9TJSL
Type: Socket
Operating temperature: -55 ℃--+125 ℃
| Product working temperature: -55℃~125℃ | Acceleration: frequency 10~2000Hz acceleration |
| Rated working current: 5A | Mechanical life: 500 times |
| Insulation resistance: normal temperature ≥5000MQ-near-end crosstalk:100ps near-end crosstalk time is not less than 30dB | Characteristic impedance: 100±15Ω |
| Withstand voltage: 800V(normal temperature) | Salt spray: 96 hours |
| Vibration: Frequency 10~2000Hz Acceleration 196m/s2-Impact: Acceleration 735m/s2 | Transmission characteristics: 1.65Gbps transmission rate
|
| Contact resistance: ≤20mΩ | Impact: acceleration 735m/s2 |
KAIDAJ30JZLN21ZKWA000connectors conform to MIL-DTL-83513 standard and are ideal for many industrial applications. It is designed to withstand harsh environmental conditions and operates over a temperature range of-55 to +125°C. due to its house material, aluminum alloy, and coupling nut, that receptacle connector has a high degree of durability and reliability. J30J-9TJSL
Type A connectors are suitable for a variety of applications such as aerospace, military and industrial systems. The connector is easy to install and provides excellent signal performance, making it a cost-effective solution for any application that requires a reliable and secure connection.
The KAIDA Micro-Cconnector is an advanced and reliable socket-type plug. ModelJ30J-9TJSL, made of copper alloy and brass, with nickel-gold plated contacts, designed for operating temperatures of-55 to +125°C. ThisMIL-C-83513connector from KAIDA is sure to meet your needs.
MIL-C-83513Connector Technical Support and Service
MIL-C-83513 connectors provide highly reliable electrical connections in harsh environments. Our technical support and services can help you get the most out of your products. technical support
Our technical support team can help you with any questions or issues regardingthe MIL-C-83513connector. We provide troubleshooting advice and technical guidance to resolve any product-related issues. Our technical support team is available 24/7 to answer your questions. product training
Our product training team will help you understand the features and specifications ofthe MIL-C-83513connector. We offer on-site and online training courses to help you get the most out of your products. Our product training team can tailor training courses to your needs and requirements. maintenance service
Our maintenance serviceprovides regular maintenance inspections and repairs for your MIL-C-83513 connector. Our maintenance team can detect any potential problems and fix them before they become a problem. We also provide regular maintenance checks to ensure your connectors are operating at peak performance.
Packaging and Transportation of MIL-C-83513 Connectors
MIL-C-83513 connectors are packaged in moisture-proof plastic bags with outer boxes sealed to protect against dust and moisture. The pouched product is then placed in a carton or other suitable container. The container is labeled with the product name, part number, and shipping address. Depending on the customer's requirements and the size of the order, the mode of transport can be air or land. The container must be marked with the product name, part number, and shipping address, as well as any special shipping information.
Instructions.
Q:What is the brand name of the MIL-C-83513 connector?
A:MIL-C-83513 connector brand name is KAIDA,
Q: What is theMIL-C-83513connector model number?
A:MIL-C-83513 connector model isJ30J-9TJSL
Q: Where is theMIL-C-83513 connector manufactured?
A:MIL-C-83513 connector is made in China.
Q: What are the benefits of usingMIL-C-83513connectors?
A:MIL-C-83513 connector has excellent performance and durability, high reliability and low insertion loss
Q: What are the applications ofMIL-C-83513connector?
A:MIL-C-83513 connectors are widely used in military and aerospace fields, such as communications, navigation, radar and data transmission.
